KATANA HABAKI GL-5 75W-90

About this item

KATANA Habaki GL-5 75W-90 – synthetic gear oil for use in hypoid, heavy loaded transmissions of buses, tractors, trucks, off-highway equipment and passenger cars operating under a wide range of loads and speeds. It is also used in other units (front and rear differential, drive axle, front hub axle, front axle, front and rear hub reduction, transfer boxes), where a manufacturer recommends to use API GL-5 oils.

KATANA Habaki GL-5 75W-90 has very high anti-wear and EP (Extreme Pressure) properties, which ensure long life of transmissions running under high loads. It can be also used in manual transmissions where the manufacturer recommends using API GL-5 oils (non synchronized gearbox) that minimizes a variety of stocks and the possibility to make a mistake.

Chemical-physical properties

Parameter

Test method

TypicalGL-5

75W-90 oil

Habaki GL-5

75W-90

Kinematic viscosity at 400С, cSt

ASTM D445

98.5

104.7

Kinematic viscosity at1000С, cSt

ASTM D445

14.7

16.4

Viscosity index

ASTM D2270

156

170

Dynamic viscosity at -400С, cP

ASTM D2983

150 000

53 000

Flash point in open cup, 0С

ASTM D92

175

188

Pour point, 0С

ASTM D97

-40

-45

TAN, mg КОН/g

ASTM D664

2

1.55

Copper corrosion

ASTM D130

2b

1b

Welding load in 4-ball machine, kg

ASTMD2596

330

400

Specifications
  • Application
    Transmission oils
  • Setting point
    -45
  • Viscosity index
    170
  • Kinematic viscosity at 40С, cS
    104.7
TDS (Technical data sheet)
